VC10 快速熔断器



Description:
The VC10 is a fast acting, full range fuse used in the protection of inverters, UPS, variable speed drives and other discrete semiconductor devices.


Features:
. Designed according to IEC269-4
. Complying with CE and RoHS
. Operating class: aR/gR
. Extremely fast acting
. Low I't for improved semiconductor protection
. Excellent cycling capability
. Current limiting


Ratings:
Voltage Rating: 690V AC(IEC)
                          700V AC(UL)
                          600V DC(UL)
                         1000V/1100VDC
Current Rating: 1A-32A
Interupt Rating: 30kA AC

产品中心

首页    半导体保护熔断器及底座    管状熔断器    VC10 快速熔断器
电压:690V(IEC)AC 700V(UL)AC
电流:1A-32A
认证:CE/UL/CUL
熔断器特性:aR/gR
符合标准:IEC269-4,UL248-13
备注:可提供带撞针指示器、PCB焊接式产品。

如需详细规格书请联系我们,E-mail: sales@maxvaton.com   Tel:0755-81705090.
