VA21

The Industry's Fastest EV(Electric Vehicle)Fuse
Assures Protection of Components and Auxiuliary Loads From the Leader in ircuit Protection.
Vicfuse EV fuses address the design factors that determine fuse life expectancy in EV applications:
VA21
Features:
.Designed refer to JASO D622
.Complying with CEand RoHS
· Operating class: gR
·Extremely fast acting
.Low l²t for improved semiconductor protection
·Excellent cycling capability
. Current limiting
Ratings:
Voltage Rating: 500VDC
Current Rating: 35A-100A
lnterrupt Rating:50kA@500VDC
