电压：500VDC
电流：700A-1000A
标准：ISO 8820-8-2012;GB/T 31465.1-2015;
           GB/T 31465.6-2017; GB/T 13539.1-2015
           GB/T 13539.4-2016

Rated voltage:500V dc
Rated current:160A-700A
Breaking capacity Max. 50kA
MinMin. ≥8In
Altitude
20002000-5000m (Derating)
Standard
IEC 60269 60269-77/UL248UL248-13
RoHS / REACH compliant
Operation class aBat/aR
TC 11-3ms
Torque M8, 12±1 Nm
Certification UL

Rated voltage:500V dc
Rated current:160A-700A
Breaking capacity Max. 50kA
MinMin. ≥8In
Altitude
20002000-5000m (Derating)
Standard
IEC 60269 60269-77/UL248UL248-13
RoHS / REACH compliant
Operation class aBat/aR
TC 11-3ms
Torque M8, 12±1 Nm
Certification UL
