LCT/LET
Rated voltage:
• LCT 240 V a.c. / 150 V d.c. (IEC)
250 V a.c. / 150 V d.c. (UL)
• LET 280 V a.c. / 150 V d.c. (UL, 25 A to 160 A)
250 V a.c. / 150 V d.c. (UL 180 A)
• Rated current: 6 A to 180 A
• Breaking capacity:
• 200 kA RMS Sym.
• 50 kA DC at 150 V d.c.
• Operating Class: aR
• LCT 240 V a.c. / 150 V d.c. (IEC)
250 V a.c. / 150 V d.c. (UL)
• LET 280 V a.c. / 150 V d.c. (UL, 25 A to 160 A)
250 V a.c. / 150 V d.c. (UL 180 A)
• Rated current: 6 A to 180 A
• Breaking capacity:
• 200 kA RMS Sym.
• 50 kA DC at 150 V d.c.
• Operating Class: aR
